型號/Model |
HCS100-2007JLM-3.15-2.5 |
HCS100-2311JLM-3.15-2.5 |
|
設備總長/Length |
7650mm |
|
|
設備總寬/Width |
2950mm |
3300mm |
|
設備總高/Height |
2100mm |
|
|
設備凈重/Net Weight |
3400kg |
3800kg |
|
裁剪高度/ Cutting Height |
7cm |
|
|
刀盤/Cutter Head |
2.5mm |
|
|
磨刀方式/ Grinding Mode |
雙輪對旋式/Double Round Disrotatory |
|
|
最高機械速度/ Maximum Speed |
60m/min |
|
|
電源/Power Supply |
380V 50Hz |
|
|
氣流量/Air Flow |
160L/min |
|
|
氣壓/Pressure |
≥0.5MPa |
|
|
最大功率/ Maximum Power |
30kW |
|
|
減速機背隙/ Reducer Backlash |
0.2° |
|
|
再覆蓋/Recover |
手動式/Manual type |
|
|
慣量推定/ Inertia Calcuation |
固定式/Stationary type |
|
|
編碼器位數/ Encoder Bits |
20位/20-bit |
|
|
移動控制方式/Moving Control Mode |
有線手柄/Cable controller |
|
|
導軌安裝/Guide Rail Installation |
底板調節式/Adjustable bottom plate |
|
|
進口/Import |
減速機/Reducer |
|
|
氣動式壓/Pneumatic Disc Locking |
X |
|
|
面向市場/Market-oriented |
針織市場/Knitting Market |
|
|
是否可定制/Customization |
X |
|
|
吸附過床/Adsorption Bed |
選配/Optional |
|
|
是否支持非移動/Whether non-mobile is supported |
接口保留/Interface reserved |
|
| 型號/Model |
|
| 設備總長/Length | 7650mm |
| 設備總寬/Width |
|
| 設備總高/Height | 2100mm |
| 設備凈重/Net Weight |
|
| 裁剪高度/ Cutting Height | 7cm |
| 刀盤/Cutter Head | 2.5mm |
| 磨刀方式/ Grinding Mode | 雙輪對旋式/Double Round Disrotatory |
| 最高機械速度/ Maximum Speed | 60m/min |
| 電源/Power Supply | 380V 50Hz |
| 氣流量/Air Flow | 160L/min |
| 氣壓/Pressure | ≥0.5MPa |
| 最大功率/ Maximum Power | 30kW |
| 減速機背隙/ Reducer Backlash | 0.2° |
| 再覆蓋/Recover | 手動式/Manual type |
| 慣量推定/ Inertia Calcuation | 固定式/Stationary type |
| 編碼器位數/ Encoder Bits | 20位/20-bit |
| 移動控制方式/Moving Control Mode | 有線手柄/Cable controller |
| 導軌安裝/Guide Rail Installation | 底板調節式/Adjustable bottom plate |
| 進口/Import | 減速機/Reducer |
| 氣動式壓/Pneumatic Disc Locking | X |
| 面向市場/Market-oriented | 針織市場/Knitting Market |
| 是否可定制/Customization | X |
| 吸附過床/Adsorption Bed | 選配/Optional |
| 是否支持非移動/Whether non-mobile is supported | 接口保留/Interface reserved |
